Servo MD1100WP

With IP67 protection, the HiTEC servo delivers dependable performance in harsh environments. A non-contact magnetic encoder provides wear-free position feedback and clean centering. Via proven PWM/TTL, the actuator ties into existing controllers, while programmability enables precise parameterization. At 14.8 V, the brushed motor reaches 0.19 s per 60° and develops 1078 N·cm (1526.6 oz·in) of torque for powerful, repeatable motion. Separate supply domains support flexible architectures: motor 9.0–16.8 V, signal 3.5–8.4 V. A steel gear train engineered for high loads transfers power efficiently and keeps operation smooth. The MD1100WP unites protection, pulling power, and precision in a compact servo for fast, secure deployment in industrial applications.
