Servo MDBX1200WP

The HiTEC servo combines high torque with precise feedback and fast response. Delivering 1078 N·cm of torque with a transit time of 0.18 s/60° at 7.4 V, the servo motor executes motion commands with powerful, dynamic performance. Its brushless DC motor supports efficient, low-wear operation, while the contactless magnetic encoder enables precise and repeatable position sensing. Instead of a conventional servo horn, the actuator features a large mounting bracket together with pre-drilled mounting points at the top and bottom of the housing. This design supports a stable mechanical connection and helps distribute loads more evenly. Control is provided via PWM or TTL, with TTL additionally supporting bidirectional communication. Thanks to IP67 protection, the servo remains reliably protected in demanding environments.
